FTTH Drop Cable Production: Manufacturing Process Explained
Quick fact: over seventy percent of new broadband deployments in the U.S. now depend on fiber networks that need precise manufacturing to hit performance targets.
Shanghai Weiye OFC Equipment runs end-to-end fiber secondary coating line manufacturing, from choosing brand fibers like Fujikura® or Corning® SMF-28e to comprehensive test documentation that ensure 100% quality assurance.
Our drop designs suit aerial, ducted, and direct-buried installation, with low-smoke zero-halogen (LSZH), PVC, and polyethylene (PE) jacket options and core counts from 1 to 4 cores. We supply single-mode OS1/OS2 and multimode OM2–OM4 grades plus G.652D and ITU-T G.657 variants, Pantone-matched sheath colors, and logo printing.
Automation and precision equipment stabilize line speed and repeatability high. Typical lead times are four to five days for orders < 100 km and 7–10 days for < 500 km, with an min. order of 1 km and free-replacement warranty for quality problems.
Continue to see how materials plus testing and support help reduce lifecycle cost and align the product to your network needs.
- Shanghai Weiye OFC Equipment offers end-to-end manufacturing and lab testing for U.S. deployments.
- A range of jacket options and optical grades cover different install environments.
- Automated production lines provide consistent quality and stable optical performance.
- Quick lead times, low MOQ, and recognized brand fibers support reliable procurement planning.
- Complete reports and warranty support product reliability and documentation needs.
FTTH Manufacturing Expertise by Shanghai Weiye OFC Equipment
When deadlines and performance are critical, Shanghai Weiye OFC Equipment provides customized drop cables with full test documentation.
As a specialized maker and supplier, Shanghai Weiye OFC Equipment pairs purpose-built equipment with stringent material control. We provide customized service and products for residential/MDU deployments. Every order includes full QA coverage and complete test reports.
Our lab conducts high-temperature, salt spray, and vibration tests to validate durability. Jacket options cover LSZH, PVC, and PE. Designs offer flat bow-type and self-supporting styles and use brand fibers such as Fujikura and Corning® SMF-28e.
- Controlled production lines and production checks for shipments with audit trails.
- Engineering support for specification reviews, trials, and volume ramp.
- Modern fixturing and calibration reduce variability so every cable meets operator standards.
How We Produce FTTH Cable
At Shanghai Weiye OFC Equipment, manufacturing steps are built around network requirements, combining brand fiber choices with strict test routines.
Selecting Optical Fiber and Brands
We match fiber draw tower to minimum bend radius, loss, and deployment type. Options include OS1/OS2 and OM2–OM4 and G.652D and G.657.A1/A2 per ITU-T. Brand fibers such as Fujikura® and Corning® SMF-28e are available to meet procurement standards.
Integrating Strength Members
Strength members use dielectric FRP or metallic steel wire. FRP is preferred where non-conductive runs are required. Steel wire provides tensile strength for longer aerial spans and grounding needs.
Jacket Options and Control
Jacket options include LSZH for indoor flame safety, PVC for flexibility, and PE for UV/moisture resistance outdoors. Tight process control of extruder temperature and capstan speed keeps line speed stable and dimensional tolerances.
| Component | Dielectric FRP | Metallic Steel |
|---|---|---|
| Primary use | Non-conductive runs | High-tension aerial runs |
| Key benefit | Lightweight, inert | High strength |
| Installation note | Easier terminations | Requires grounding |
In-Process and Final Testing
Inline geometry and concentricity checks operate in-line. Final optical tests verify attenuation and return loss. Each order includes a 100% test report and lab results from high-temperature, salt fog, and vibration trials to confirm handling for drop terminations and field use.
Typical lead times are 4–5 days for < 100 km and 7–10 days for < 500 km. Lot records and FAI approvals support traceability and compliance for U.S. projects.
FTTH drop cable types and structures we manufacture
Shanghai Weiye OFC Equipment offers a focused portfolio of FTTH drop designs that fit indoor risers and long aerial runs. Each option combines tested materials with field-termination geometry and consistent optical performance.
The flat bow-type drop minimizes footprint for risers/ducts. It reduces bend loss for easy routing in hallways and MDUs.
Aerial Self-Supporting Options
Self-supporting FTTH drop designs use a messenger element to handle tension. Choose FRP (dielectric) for electrical isolation or steel wire when bonding and extra tensile strength are required.
Strength member and core layouts
We provide both dielectric and metallic strength member configurations to meet safety/EMI requirements. Central loose-tube and flat unitube types balance crush resistance and Fiber draw tower for quick termination.
Jackets for Indoor/Outdoor
Jacket choices include LSZH for flame-retardant, low-smoke indoor use and PE for outdoor durability. Each family is qualified for mechanical and optical quality before shipment.
| Design | Best use | Strength element | Sheath |
|---|---|---|---|
| Bow-type flat | Indoor risers and MDUs | FRP (dielectric) | LSZH |
| Self-supporting | Aerial spans | FRP/Steel | PE |
| Central loose-tube | Higher-count builds | Dielectric FRP | LSZH or PE |
| Flat unitube | Low count, quick strip | FRP/Steel | LSZH/PE |
Production Assets for Speed and Quality
Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment cut manual handling and boost throughput for drop patch preparation.
Our production line integrates automated machines that cut and strip drop patch cords to increase output and cut labor variability.
The CLX-BPO2 automated stripper uses PLC + photoelectric control. One cycle is about 1.5 seconds, giving ~20 terminals per minute in production.
Automated cutting and stripping for drop cable patch cords
The equipment strips LSZH and PVC jackets and trims FRP/steel members to precise reserved lengths. Pneumatic cylinder actuators provide quick, repeatable motion and minimize downtime.
PLC/photoelectric control for precision and repeatability
PLC logic and photoelectric sensors give exact positioning and feedback control. Inline checks update SPC charts so operators can correct trends before defects grow.
| Item | Capability | Result |
|---|---|---|
| CLX-BPO2 | 1.5s cycle, auto-strip | High throughput |
| Actuation | Cylinder-based | High speed and reliability |
| Materials | LSZH & PVC; FRP & steel | Accurate stubs, clean terminations |
| Process control | PLC/photoelectric with in-line SPC | Stable quality, reduced rework |
- Automated waste ejection and ergonomic feeders keep the line clean.
- PCPs document calibration and key parameters.
- Combined machines, fixtures, and trained staff support FTTH volume targets without sacrificing accuracy.
CLX-BPO2 Capabilities on Our Line
The CLX-BPO2 brings industrial-grade stripping and trimming to our line, cutting cycle time while maintaining consistent prep.
Shanghai Weiye OFC Equipment deploys the CLX-BPO2 to raise output and standardize terminal quality. The unit runs at an approximate cycle time of 1.5 seconds, producing around 20 preps per minute in production.
PLC/photoelectric control enable precise detection and repeatable motion. That control helps keep strip lengths and reserved strength stubs within tight tolerances.
Cycle time and throughput
Typical operation speed is 1.5s per cycle. This converts to steady throughput under continuous line conditions.
Supported jacket and reserved strength lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable strip length from 17.5–35.0 mm. Reserved stubs are adjustable from 7.0–11.0 mm to match common termination hardware.
Cutting FRP/Steel Members
The machine cleanly cuts FRP and steel wire strength elements while protecting neighboring fibers. Custom tooling are offered for nonstandard sizes to preserve precision.
- Auto-eject scrap and sensor-triggered start reduce idle time.
- Small footprint (L40 × W18 × H18 cm), 50W at 110–220V, and 11 kg mass simplify cell integration.
- Cylinder-driven motion and closed-loop control boost reliability and reduce maintenance downtime.
| Spec | Value | Benefit |
|---|---|---|
| Cycle | ≈1.5 s (~20/min) | High throughput for production runs |
| Jacket strip (A) | 17.5–35.0 mm | Fits common connector processes |
| Reserved stub (B) | 7.0 to 11.0 mm | Supports termination strength |
| Power & size | 110–220V, 50W; 40×18×18 cm | Easy integration into existing equipment |
Using this machine, Shanghai Weiye OFC Equipment standardizes terminal prep so field teams get drop parts install-ready. The CLX-BPO2 helps our production lines meet volume goals without compromising quality.
Custom Specs for Your FTTH System
Shanghai Weiye OFC Equipment configures each build to meet your network requirements and simplify field rollout. We combine focused options with predictable schedules so your teams get install-ready reels.
Choose 1–4 core designs with single-mode or multimode fiber. Options include OS1/OS2 plus OM2–OM4 plus G.652D/G.657 variants to match your optics and connector plans.
We Pantone-match sheath colors for quick field identification and consistent asset tags.
Branding and Print Options
Select LSZH, PVC, or PE jackets to suit route and safety requirements. Custom legends/logos aid inventory/warranty tracking.
Put-Ups, Packaging, and Structures
Standard put-ups are 1/2/4 km with tailored reels and packaging to suit storage and handling. Choose bow-type flat or self-supporting designs and FRP or steel members to meet span and isolation needs.
| Choice | Common choice | Advantage |
|---|---|---|
| Reel length | 1, 2, or 4 km | Simpler staging and reels |
| Sheath | LSZH, PE, PVC | Indoor/Outdoor fit |
| Design | Bow-type / Self-supporting | Routing and span flexibility |
As a manufacturer, Shanghai Weiye schedules runs to your plan and delivers documentation that lists final specifications for straightforward QA on site.
Quality, Test, and Docs
Shanghai Weiye OFC Equipment embeds quality checkpoints across the production line so every item has recorded acceptance data at ship.
Environmental and Mechanical Tests
Our lab conducts elevated-temperature exposure, salt spray corrosion, and mechanical vibration to qualify materials and assemblies. These tests recreate field stresses for indoor and outdoor use.
Full Test Reports for Every Reel
Every fiber optic cable includes a 100% test report that logs attenuation, return loss, and geometry where applicable. Final inspection gates prevent nonconforming shipments before they leave the factory.
Traceability & Compliance
Lot/batch records link tests to reels/serials so audits and warranty claims are simple to verify. Documentation uses standard customer templates to accelerate approvals and receiving inspection.
- In-line checks plus final inspection prevent field failures and cut warranty events.
- QA packages include spec confirmation and formatted test data for quick review.
- Ongoing trend analysis drive preventive maintenance and improve long-term reliability.
| Test | Why | Outcome |
|---|---|---|
| High-temperature | Material stability | Pass at target temperature |
| Salt spray | Corrosion robustness | Outdoor suitability |
| Vibration | Mechanical robustness | Reduced field failures |
FTTH Drop Cable Pricing & Cost Drivers
Budgeting for a drop run begins with fiber/jacket selection and is refined by volume and customization.
Typical prices range broadly—from about $30–$1,000 per unit—based on fiber grade, jacket material, length, and structural design.
Primary Cost Inputs
The primary cost drivers are fiber optic grade, jacket material, and the structural type chosen for deployment.
Self-supporting structures and steel strength elements raise material and labor input. Custom colors, logos, and print legends add setup and influence price for short runs.
Order length, volume, and customization impact on price
Longer put-ups and larger volumes reduce unit cost. Small quantities often carry setup fees and higher unit prices.
- Line changeovers and custom tooling increase lead time and add to cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Frameworks and indexed pricing stabilize budgets over phases.
| Driver | Price impact | Guidance |
|---|---|---|
| Optical grade | High impact | Right-size spec to budget |
| Jacket type | Medium | Evaluate LSZH vs PE |
| Length/Volume | Large | Consolidate runs to cut unit cost |
U.S. Lead Times, MOQ & Delivery
Shanghai Weiye OFC Equipment makes lead times and logistics clear so planners can align staffing and sites. Predictable windows reduce downtime and help control cost when a rollout is underway.
Scheduling & Capacity Planning
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for < 500 km. We plan capacity to track your milestones and to maintain on-time delivery.
The service team issues production updates and tracking so installation teams know when reels arrive. For compressed schedules, we hold contingency capacity to accelerate critical-path orders.
Why MOQ Matters
The MOQ is 1 km. This reflects setup needs such as wire/die adjustments that use startup material and generate scrap.
We review your put-ups and staging to select reels to reduce waste/handling. Staggered batches can balance inventory with more frequent small-site deliveries.
Installation Scenarios & Readiness
On-site conditions dictate whether a self-supporting span, duct pull, or direct burial is the best fit for a project.
Aerial, duct, and direct-buried deployment considerations
For aerial runs, Shanghai Weiye OFC Equipment advises self-supporting designs with appropriate members to control sag and tension for long-term reliability.
Duct installations work best with low-friction sheaths and crush-resistant constructs so pulling does not damage fibers. PE jackets are common for underground and buried paths where moisture resistance matters.
Direct-buried designs require proper depth control per local codes and moisture-resistant jackets to protect the fiber core long-term.
Indoor riser/plenum distribution and ONT termination
Indoor riser/plenum routes favor LSZH jackets to meet flame and smoke rules. Flat drop profiles strip clean and present controlled strength stubs for quick ONT termination.
We guide the choice of steel or FRP (dielectric) strength members based on bonding needs, lightning exposure, and hardware compatibility. Standardized line prep reduces install time and reduces scrap.
| Scenario | Key design | Installer note |
|---|---|---|
| Overhead | Self-supporting, steel or FRP | Verify messenger hardware/tension |
| Duct | Low-friction, crush-resistant | Use pull tape and proper lubricant |
| Direct burial | PE with moisture barrier | Follow depth/warning tape codes |
| Indoor | LSZH jacket, tight bend support | Maintain bend radius at wall penetrations |
Our approach delivers a consistent installation across indoor outdoor transitions. That leads to fewer callbacks, faster activations, and reliable field performance for your system.
End-to-end support and after-sales service
Our team coordinates tests, line schedules, and installation guidance to remove surprises during deployment.
Shanghai Weiye OFC Equipment offers engineering support from early requirements capture through approved drawings and pilot builds. We deliver documentation templates and clear installation notes so field crews work from the same plan.
After-sales service includes fast response, RCA, and corrective action. All products ship with full reports and traceability to support QA acceptance.
- 24/7 availability for status updates and technical guidance.
- Warranty with free replacement if any quality problems are confirmed.
- Coordination of line schedules for urgent changes or acceleration requests.
- Configuration control so shipped items match agreed requirements every time.
| Support area | Scope | Benefit |
|---|---|---|
| Engineering | Spec review & pre-production builds | Reduced field issues |
| QA/Testing | Lab + 100% reports | Full traceability |
| After-sales | Fast replace + RCA | Lower downtime |
Conclusion
Choose Shanghai Weiye OFC Equipment for tailored drop builds, short lead times, and traceable quality records.
We provide custom FTTH drops that combine materials with validated manufacturing and lab tests. Every reel ships with a 100% test report and documented trials to support U.S. field acceptance.
A robust production line, including CLX-BPO2 prep assets, cuts variability and speeds turnaround. Our equipment set standardize strip/stub lengths so installers get consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance design and cost to extend service life. Dedicated support covers scheduling/logistics/after-sales so your deployment remains on plan.
Contact Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every fiber optic and optic cable shipment with lab validation and responsive service.
